- Conveniently behavior with electro-hydraulic direction changing lever and automobile type double joystick combined switch;
- LPG&Gasoline Forklift's power is LPG or both,can be dual fuel or single fuel .Usually it equip The operator`s legroom is twice to other series with optimized construction;
- LPG & Gasoline combustion fully, improve the life of engine three times. It`s more clean than Diesel Forklift,and can work longer than Electric Forklift.
- Small diameter steering wheel reduces driver`s left shoulder`s fatigue and makes driving comfortable;
- Suspension seat with handrail and seat belt ensure the operator`s safety and comfort;
- The dynamic braking system decreases the braking force sharply.
FG40L-FG45L
|
General |
|
|
|
|
|
Model |
|
FG40L |
FG45L |
|
|
Power Type |
|
LPG |
LPG |
|
|
Drive Type |
|
Sit |
Sit |
|
|
Load Capacity |
kg |
4000 |
4500 |
|
|
Load centre |
mm |
500 |
500 |
|
|
Tyre |
|
|
|
|
|
Tyre Type |
|
|
Pneumatic Tyre |
Pneumatic Tyre |
|
|
|
|
4X/2 |
4X/2 |
|
Front Tyre |
|
3.00-15-1PR |
3.00-15-18PR |
|
|
Rear Tyre |
|
7.00-12-12PR |
7.00-12-12PR |
|
|
Lift Height |
mm |
3000 |
3000 |
|
|
Fork Size |
L×W×T |
mm |
1220×150×60 |
1220×150×60 |
|
Mast Tilt Angle |
F/R |
. |
6/12 |
6/12 |
|
Mast Lowered Height |
mm |
2270 |
2270 |
|
|
Mast Extended Height(with backrest) |
mm |
4110 |
4110 |
|
|
Length to face of fork(Without fork) |
mm |
3245 |
3245 |
|
|
Overall Width |
mm |
1430 |
1430 |
|
|
Overhead Guard Height |
mm |
2265 |
2265 |
|
